Autumn at the Hermitage

I spent a happy several hours wandering around The Hermitage by Dunkeld over the weekend, taking in very much the end of nature’s autumn displays – tree foliage fallen and fading, the light dull overcast all afternoon (and mostly raining, at that).

First, a few conventional scenes beside the River Braan and the Black Linn waterfalls from the bridge, as one does:

From there I explored a new direction away from the river, up through the Craigvinean woods to the Pine Cone viewpoint. The weather descended – from bright sunshine strolling through the colourful larches, it turned completely dreich grey and mist arose from the trees reducing visibility to barely 50yd. Quite spooky 🙂

On the way back, a particular beech tree caught my attention; with a bit of work, the 18mm prime revealed a particularly strong composition, illustrating the tree’s curving trunk. An unusual use for focus-stacking, too: it was so dark when I started the sequence, the camera was at 30s, ISO 400 even at f/2.0; by the time I finished 8 minutes layer, it was completely pitch black night.





Portknockie

Continuing the mega road-trip drive from a day in April: having taken in Dunnottar castle I proceeded up to Portknockie on the north Moray coast. A well-known location with lots of scope to explore, sitting on a transition between red sandstone conglomerate and quartzite underlying rock.



Bow-Fiddle rock itself is situated just beyond the mouth of a cove with interesting caves to the north side:

The approach to Bow-Fiddle rock at Portknockie.
We’re heading down to that strip of a pebble beach…

There’s a classic composition to be had by heading down to the boulders just beyond the pebble beach, plonking one’s tripod on the rock and adding enough ND filters to make a long exposure. With the right light and the wind kicking-up choppy waves, it can make for pleasantly dramatic arty photos. And despite being a sunny day, having to lie down on the hard rock to keep my shadow out of the shot, it definitely didn’t disappoint…

Technical details:

Pentax K-1; Samyang 24mm f/1.4 lens at f/11; Nisi ND1000 (equivalent to a Big Stopper) and circular polariser filters; ISO 100; 30s exposure using pixel-shift for a total of 2 minutes’ exposure at high resolution.

Moody Eclipse Photos

I was up early on the morning of March 20th to get to Stonehaven on the coast in time for the solar eclipse.

It’s funny how there was so much discussion as to what filters one should use when shooting the sun: on the one hand, a direct view of the sun’s disc requires special Baader solar filter (approx 23 stops’ filtration); however, when I arrived to see the extent of the clouds, only conventional photographic filters were needed (a mixture of ND1000 and circular polarizer 2-stop filters). And I think the results were all the more dramatic for it, too.

The first of these photos was made using a Centon 500mm mirror lens over 20 years old – from when I bought my first film SLR (a Canon EOS500n – that dates it) It even shows sunspot N 2303 pretty clearly.

The others are with the Sony 55-210mm lens at full stretch instead.

Each image is an HDR of 3 source frames bracketed +/-1EV, converted in photivo, blended in enfuse and worked in darktable.

It’s been a while…

It’s been a few months now since I called time on the fixation with black&white closeup as a style. So it’s time to remember how to do it… Herewith, mostly as a lens-test, cyclamen and cactus plants from the kitchen windowsill.

Since I last looked, RawTherapee has changed a lot – I’ve learned that the `Contrast by Details’ control was responsible for some undesirable noisy artefacts in previous profiles, it’s gained better control over black and white conversion and even support for X-Trans sensors (now there’s something to lust after).

Fern Bokeh

Ferns

Ferns

The past couple of days I’ve been experimenting with the old Pentacon 50mm f/1.8 lens; its bokeh wide-open is quite spectacular, giving this small scene a strong sense of depth.

Approach Routes

Time for something a little different.

With the previous camera, I was particularly fond of an old Pentacon 50mm f/1.8 prime lens; an awful lot of my photos were made using that, especially for closeups and even some landscapes. On the Lumix GH2, with its 2x crop-factor, this was the equivalent of shooting at 100mm-e all the time, and I was very familiar with the field of view that entailed.

Now I’ve switched to the Sony NEX-7, I’m experimenting more with wide-angle field of view. It feels completely different, as though the eye is latching-on to features of a scene I would not previously have considered using, especially the idea of perspective and lines leading into the distance.

Yesterday’s photo of the day was taken in the Fairy Glen in Portpatrick:

Between Realities

Between Realities – in the Fairy Glen, Portpatrick

and today I dug out an old Peleng 8mm fisheye lens, spent a while tweaking the screws in the M42->E-mount adapter to make it focus at all, and made this image of the approach to the harbour – a 170-degree field of view:

Approach Routes

Approach Routes

Coincidentally, both images have also been processed using LuminanceHDR for tonemapping.

Knowing Your Lenses

Analysing Lens Performance

Background

Typically, when a manufacturer produces new lenses, they include an MTF chart to demonstrate the lens’s performance – sharpness measured as the number of line-pairs per millimetre it can resolve (to a given contrast tolerance), radially and sagitally, varying with distance from the centre of the image. While this might be useful before purchasing a lens, it does not make for easy comparisons (what if another manufacturer uses a different contrast tolerance?) nor does it necessarily well reflect the use to which it’ll be put in practice. (What if they quote a zoom’s performance at 28mm and 70mm f/5.6, but you shoot it most at 35mm f/8? Is the difference between radial and sagittal sharpness useful for a real-world scene?)
Further, if your lens has been around in the kit-bag a bit, is its performance still up to scratch or has it gone soft, with internal elements slightly out of alignment? When you’re out in the field, does it matter whether you use 50mm in the middle of a zoom or a fixed focal-length prime 50mm instead?
If you’re shooting landscape, would it be better to hand-hold at f/5.6 or stop-down to f/16 for depth of field, use a tripod and risk losing sharpness to diffraction?
Does that blob of dust on the front element really make a difference?
How bad is the vignetting when used wide-open?

Here’s a fairly quick experiment to measure and compare lenses’ performance by aperture, two ways. First, we design a test-chart. It’s most useful if the pattern is even across the frame, reflecting a mixture of scales of detail – thick and thin lines – at a variety of angles – at least perpendicular and maybe crazy pseudo-random designs. Here’s a couple of ideas:

Method

Decide which lenses, at which apertures, you want to profile. Make your own design, print it out at least A4 size, and affix it to a wall. We want the lighting to be as even as possible, so ideally use indoor artificial light after dark (ie this is a good project for a dark evening). Carefully, set up the camera on a tripod facing the chart square-on, and move close enough so the test-chart is just filling the frame.

Camera settings: use the lowest ISO setting possible (normally around 100), to minimize sensor noise. Use aperture-priority mode so it chooses the shutter-speed itself and fix the white-balance to counteract the indoor lighting. (For a daylight lightbulb, use daylight; otherwise, fluorescent or tungsten. Avoid auto-white-balance.)
Either use a remote-release cable or wireless trigger, or enable a 2-second self-timer mode to allow shaking to die down after pushing the shutter. Assuming the paper with the test-chart is still mostly white, use exposure-compensation (+2/3 EV).
For each lens and focal-length, start with the widest aperture and close-down by a third or half a stop, taking two photos at each aperture.
Open a small text-document and list each lens and focal-length in order as you go, along with any other salient features. (For example, with old manual prime lenses, note the start and final apertures and the interval size – may be half-stops, may be third of a stop.)
Use a RAW converter to process all the images identically: auto-exposure, fixed white-balance, and disable any sharpening, noise-reduction and rescaling you might ordinarily do. Output to 16-bit TIFF files.

Now, it is a given that a reasonable measure of pixel-level sharpness in an image, or part thereof, is its standard deviation. We can use the following Python script (requires numpy and OpenCV modules) to load image(s) and output the standard deviations of subsets of the images:

#!/usr/bin/env python

import sys, glob, cv, cv2
import numpy as np

def imageContrasts(fname):
  img = cv2.imread(fname, cv.CV_LOAD_IMAGE_GRAYSCALE)
  a=np.asarray(img)
  width=len(img[0])
  height=len(img[1])
  half=a[0:height//3, 0:width//3]
  corner=a[0:height//8, 0:width//8]
  return np.std(a), np.std(half), np.std(corner)

def main():
	files=sys.argv[1:]
	if len(files)==0:
		files=glob.glob("*.jpg")
	for f in files:
		co,cc,cf=imageContrasts(f)
		print "%s contrast %f %f %f" % (f, co, cc, cf)

if __name__=="__main__":
	main()

We can build a spreadsheet listing the files, their apertures and sharpnesses overall and in the corners, where vignetting typically occurs. We can easily make a CSV file by looping the above script and some exiftool magic across all the output TIFF files:

bash$ for f in *.tif
do
ap=$(exiftool $f |awk '/^Aperture/ {print $NF}' )
speed=$( exiftool $f |awk '/^Shutter Speed/ {print $NF}' )
conts=$(~/python/image-interpolation/image-sharpness-cv.py $f | sed 's/ /,/g')
echo $f,$ap,=$speed,$conts
done

Typical output might look like:

P1440770.tif,,=1/20,P1440770.tif,contrast,29.235214,29.918323,22.694936
P1440771.tif,,=1/20,P1440771.tif,contrast,29.253372,29.943765,22.739748
P1440772.tif,,=1/15,P1440772.tif,contrast,29.572350,30.566767,25.006098
P1440773.tif,,=1/15,P1440773.tif,contrast,29.513443,30.529055,24.942437

Note the extra `=’ signs; on opening this in LibreOffice Spreadsheet, the formulae will be evaluated and fractions converted to floating-point values in seconds instead. Remove the spurious `contrast’ column and add a header column (fname,aperture,speed,fname,overall,half,corner).

Analysis

Let’s draw some graphs. If you wish to stay with the spreadsheet, use a pivot table to average the half-image contrast values per aperture per lens and work off that. Alternatively, a bit of interactive R can lead to some very pretty graphs:

> install.package(ggplot2)
> library(ggplot2)
> data<-read.csv("sharpness.csv")
> aggs<-aggregate(cbind(speed,entire,third,corner) ~lens+aperture, data, FUN=mean)
> qplot(aggs$aperture, aggs$third, col=aggs$lens, data=aggs, asp=.5)+geom_smooth()

This will give a comparison of overall sharpness by aperture, grouped by lens. Typically we expect every lens to have a sweetspot aperture at which it is sharpest; my own examples are no exception: third There are 5 lenses at play here: a kit 14-42mm zoom, measured at both 30mm and 42mm; a Minolta Rokkor 55mm prime; a Pentacon 30mm prime; and two Pentacon 50mm f/1.8 prime lenses, one brand new off eBay and one that’s been in the bag for 4 years.

The old Pentacon 50mm was sharpest at f/5.6 but is now the second-lowest at almost every aperture – we’ll come back to this. The new Pentacon 50mm is sharpest of all the lenses from f/5 onwards, peaking at around f/7.1. The kit zoom lens is obviously designed to be used around f/8; the Pentacon 30mm prime is ludicrously unsharp at all apertures – given a choice of kit zoom at 30mm or prime, it would have to be the unconventional choice every time. And the odd one out, the Rokkor 55mm, peaks at a mere f/4.

How about the drop-off, the factor by which the extreme corners are less sharp than the overall image? Again, a quick calculation and plot in R shows:

> aggs$dropoff < - aggs$corner / aggs$third
> qplot(aggs$aperture, aggs$dropoff, col=aggs$lens, data=aggs, asp=.5)+geom_smooth()

dropoff Some observations:

  • all the lenses show a similar pattern, worst vignetting at widest apertures, peaking somewhere in the middle and then attenuating slightly;
  • there is a drastic difference between the kit zoom lens at 30mm (among the best performances) and 42mm (the worst, by far);
  • the old Pentacon 50mm lens had best drop-off around f/8;
  • the new Pentacon 50mm has least drop-of at around f/11;
  • the Minolta Rokkor 55mm peaks at f/4 again.

So, why do the old and new Pentacon 50mm lenses differ so badly? Let’s conclude by examining the shutter-speeds; by allowing the camera to automate the exposure in aperture-priority mode, whilst keeping the scene and its illumination constant, we can plot a graph showing each lens’s transmission against aperture.

> qplot(aggs$aperture, log2(aggs$speed/min(aggs$speed)), col=aggs$lens, data=aggs, asp=.5)+geom_smooth()

speed Here we see the new Pentacon 50mm lens seems to require the least increase in shutter-speed per stop aperture, while, above around f/7.1, the old Pentacon 50mm lens requires the greatest – rocketing off at a different gradient to everything else, such that by f/11 it’s fully 2 stops slower than its replacements.

There’s a reason for this: sadly, the anti-reflective coating is starting to come off in the centre of the front element of the old lens, in the form of a rough circle approximately 5mm diameter. At around f/10, the shutter iris itself is 5mm, so this artifact becomes a significant contributor to the overall exposure.

Conclusion

With the above data, informed choices can be made as to which lens and aperture suit particular scenes. When shooting a wide-angle landscape, I can use the kit zoom at f/8; for nature and woodland closeup work where the close-focussing distance allows, the Minolta Rokkor 55mm at f/4 is ideal.
